Luxe Manual Louvered Roof Pergola
Good things take time, and our new Luxe Retractable Pergola was worth the wait.
A UK exclusive, we’re bringing you signature Suns Lifestyle quality and construction, seamlessly combined with market-leading innovation. You won’t find these options anywhere else.
Our signature manual louvered roof system gets an upgrade. Developed with invaluable customer feedback, we’ve enhanced our original contemporary manual louvered pergola to give you even more comfort and control over the build options for a space that suits your needs and lifestyle perfectly. Add manual retractable screens or louvered panels.
Crafted from industrial-grade aluminium, the Luxe pergola can be tailored to any size and space with buildable base kits. This is our most bespoke pergola kit yet. Although created in standard sizes as listed, we can configure a large range of variable sizes to suit all with this model. For more information about the new Luxe Pergola, please get in touch!
Pre-order available for August/September 2024 for particular sizes.
A premium product built using high quality materials
No planning permission required
Weatherproof for all year use
Flexible Features
-
Measurement from the top of your doors to the patio floor.
-
Measurement of the brick/stonework between the top of your doors and soffit (if there is one).
-
Measurement of patio door width.
-
Measurement from the patio floor to the underside of soffit (if there is one).
-
Measurement from the patio floor to the underside of the gutter (if there is one).
-
Length of your patio or decking.
-
Width of your patio or decking.
If you need any further support or queries on pergola sizing and dimensions please take some photos of your space, marking up the measurements in colour and contact our team of pergola experts today.
| 3M Base / 4 Legs | 3.0 x 2.75 | 3.0 x 3.0 | 3.0 x 3.60 | 3.0 x 4.0 |
|---|---|---|---|---|
| A Width (m) | 3.05 | 3.05 | 3.05 | 3.05 |
| B Length (m) | 2.75 | 3.05 | 3.65 | 3.95 |
| C Inside footplate length (m) | 2.51 | 2.81 | 3.41 | 3.71 |
| D Height (m) | 2.50 | 2.50 | 2.50 | 2.50 |
| E Inside footplate width (m) | 2.81 | 2.81 | 2.81 | 2.81 |
| 3M Base / 6 Legs | 3.0 x 5.4 | 3.0 x 6.0 | 3.0 x 7.20 | 3.0 x 8.0 |
|---|---|---|---|---|
| A Width (m) | 3.05 | 3.05 | 3.05 | 3.05 |
| B Length (m) | 5.38 | 5.98 | 7.18 | 7.78 |
| C Inside footplate length (m) | 2.51 | 2.81 | 3.41 | 3.71 |
| D Height (m) | 2.50 | 2.50 | 2.50 | 2.50 |
| E Inside footplate width (m) | 2.81 | 2.81 | 2.81 | 2.81 |
| 3M Base / 8 Legs | 3.0 x 9.0 | 3.0 x 10.0 | 3.0 x 11.0 | 3.0 x 12.0 |
|---|---|---|---|---|
| A Width (m) | 3.05 | 3.05 | 3.05 | 3.05 |
| B Length (m) | 8.91 | 9.81 | 10.71 | 11.61 |
| C Inside footplate length (m) | TBC | TBC | TBC | TBC |
| D Height (m) | 2.50 | 2.50 | 2.50 | 2.50 |
| E Inside footplate width (m) | 2.81 | 2.81 | 2.81 | 2.81 |
| 3.6M Base / 4 Legs | 3.6 x 2.75 | 3.6 x 3.0 | 3.6 x 3.6 | 3.6 x 4.0 |
|---|---|---|---|---|
| A Width (m) | 3.65 | 3.65 | 3.65 | 3.65 |
| B Length (m) | 2.75 | 3.05 | 3.65 | 3.95 |
| C Inside footplate length (m) | 2.51 | 2.81 | 3.41 | 3.71 |
| D Height (m) | 2.50 | 2.50 | 2.50 | 2.50 |
| E Inside footplate width (m) | 3.41 | 3.41 | 3.41 | 3.41 |
| 3.6M Base / 6 Legs | 3.6 x 5.4 | 3.6 x 6.0 | 3.6 x 7.2 | 3.6 x 8.0 |
|---|---|---|---|---|
| A Width (m) | 3.65 | 3.65 | 3.65 | 3.65 |
| B Length (m) | 5.38 | 5.98 | 7.18 | 7.78 |
| C Inside footplate length (m) | 2.51 | 2.81 | 3.41 | 3.71 |
| D Height (m) | 2.50 | 2.50 | 2.50 | 2.50 |
| E Inside footplate width (m) | 3.41 | 3.41 | 3.41 | 3.41 |
| 3.6M Base / 8 Legs | 3.6 x 9.0 | 3.6 x 10.0 | 3.6 x 11.0 | 3.6 x 12.0 |
|---|---|---|---|---|
| A Width (m) | 3.65 | 3.65 | 3.65 | 3.65 |
| B Length (m) | 8.91 | 9.81 | 10.71 | 11.61 |
| C Inside footplate length (m) | TBC | TBC | TBC | TBC |
| D Height (m) | 2.50 | 2.50 | 2.50 | 2.50 |
| E Inside footplate width (m) | 3.41 | 3.41 | 3.41 | 3.41 |
Assembly
Materials
Cleaning & care
Download our Pergola Comparison Guide to view the specs of all Suns Lifestyle pergolas and see what fits your space best. Alternatively, get in touch with our expert team and they’ll be happy to discuss your requirements.
