Luxe Electric Retractable Roof LED Pergola
Good things take time, and our new Luxe Electric Retractable Pergola was worth the wait.
A UK exclusive, we’re bringing you signature Suns Lifestyle quality and construction, seamlessly combined with market-leading innovation. You won’t find these options anywhere else.
Crafted from industrial-grade aluminium, the Luxe pergola can be tailored to any size and space with buildable base kits. This is our most bespoke pergola kit yet. Choose your size and layout, including L and U-shaped custom builds. Add your retractable side screens or louvered panels to give you an outdoor extension to your home like no other.
The fully integrated, exclusive Suns Lifestyle app gives you complete control over the roof louver mechanism, LED lighting and side screens at the touch of a button.
Although created in standard sizes we can configure a large range of variable sizes to suit all with this model, for more information about the new Luxe Electric Retractable Pergola please contact us.
Pre-order available for selected sizes and colours of our Luxe Pergolas, please call 01277 321888 or email sales@sunslifestyle.com to reserve yours.
A premium product built using high quality materials
No planning permission required
Weatherproof for all year use
Flexible Features
-
Measurement from the top of your doors to the patio floor.
-
Measurement of the brick/stonework between the top of your doors and soffit (if there is one).
-
Measurement of patio door width.
-
Measurement from the patio floor to the underside of soffit (if there is one).
-
Measurement from the patio floor to the underside of the gutter (if there is one).
-
Length of your patio or decking.
-
Width of your patio or decking.
If you need any further support or queries on pergola sizing and dimensions please take some photos of your space, marking up the measurements in colour and contact our team of pergola experts today.
| 3M Base / 4 Legs | 3.0 x 2.75 | 3.0 x 3.0 | 3.0 x 3.60 | 3.0 x 4.0 |
|---|---|---|---|---|
| A Width (m) | 3.05 | 3.05 | 3.05 | 3.05 |
| B Length (m) | 2.75 | 3.05 | 3.65 | 3.95 |
| C Inside footplate length (m) | 2.51 | 2.81 | 3.41 | 3.71 |
| D Height (m) | 2.50 | 2.50 | 2.50 | 2.50 |
| E Inside footplate width (m) | 2.81 | 2.81 | 2.81 | 2.81 |
| 3M Base / 6 Legs | 3.0 x 5.4 | 3.0 x 6.0 | 3.0 x 7.20 | 3.0 x 8.0 |
|---|---|---|---|---|
| A Width (m) | 3.05 | 3.05 | 3.05 | 3.05 |
| B Length (m) | 5.38 | 5.98 | 7.18 | 7.78 |
| C Inside footplate length (m) | 2.51 | 2.81 | 3.41 | 3.71 |
| D Height (m) | 2.50 | 2.50 | 2.50 | 2.50 |
| E Inside footplate width (m) | 2.81 | 2.81 | 2.81 | 2.81 |
| 3M Base / 8 Legs | 3.0 x 9.0 | 3.0 x 10.0 | 3.0 x 11.0 | 3.0 x 12.0 |
|---|---|---|---|---|
| A Width (m) | 3.05 | 3.05 | 3.05 | 3.05 |
| B Length (m) | 8.91 | 9.81 | 10.71 | 11.61 |
| C Inside footplate length (m) | TBC | TBC | TBC | TBC |
| D Height (m) | 2.50 | 2.50 | 2.50 | 2.50 |
| E Inside footplate width (m) | 2.81 | 2.81 | 2.81 | 2.81 |
| 3.6M Base / 4 Legs | 3.6 x 2.75 | 3.6 x 3.0 | 3.6 x 3.6 | 3.6 x 4.0 |
|---|---|---|---|---|
| A Width (m) | 3.65 | 3.65 | 3.65 | 3.65 |
| B Length (m) | 2.75 | 3.05 | 3.65 | 3.95 |
| C Inside footplate length (m) | 2.51 | 2.81 | 3.41 | 3.71 |
| D Height (m) | 2.50 | 2.50 | 2.50 | 2.50 |
| E Inside footplate width (m) | 3.41 | 3.41 | 3.41 | 3.41 |
| 3.6M Base / 6 Legs | 3.6 x 5.4 | 3.6 x 6.0 | 3.6 x 7.2 | 3.6 x 8.0 |
|---|---|---|---|---|
| A Width (m) | 3.65 | 3.65 | 3.65 | 3.65 |
| B Length (m) | 5.38 | 5.98 | 7.18 | 7.78 |
| C Inside footplate length (m) | 2.51 | 2.81 | 3.41 | 3.71 |
| D Height (m) | 2.50 | 2.50 | 2.50 | 2.50 |
| E Inside footplate width (m) | 3.41 | 3.41 | 3.41 | 3.41 |
| 3.6M Base / 8 Legs | 3.6 x 9.0 | 3.6 x 10.0 | 3.6 x 11.0 | 3.6 x 12.0 |
|---|---|---|---|---|
| A Width (m) | 3.65 | 3.65 | 3.65 | 3.65 |
| B Length (m) | 8.91 | 9.81 | 10.71 | 11.61 |
| C Inside footplate length (m) | TBC | TBC | TBC | TBC |
| D Height (m) | 2.50 | 2.50 | 2.50 | 2.50 |
| E Inside footplate width (m) | 3.41 | 3.41 | 3.41 | 3.41 |
Our professional install team will bring the pergola kit with them and install everything on the day. Before they start, they'll recap on positioning with you to double check you're happy.
Download our Pergola Comparison Guide to view the specs of all Suns Lifestyle pergolas and see what fits your space best. Alternatively, get in touch with our expert team and they’ll be happy to discuss your requirements.
Our friendly team are on hand to answer any questions you might have, simply pop us an email or pick up the phone and we’ll happily answer any questions or queries you might have.
